Corrugation System

Corrugation used to improve and optimize the thermal exchange in the tubular exchangers. It is a particular machining applied on plain tubes to induce local turbulence during the liquids flowing.

With corrugated tubes the thermal exchange efficiency can be enhanced by 40% up to 92% according to the following parameters:

• - type of product
• - selected profile
• - type of application

      Technical features

• - Wetted parts in AISI 304, 316 and 316L Cr-Ni steel.
• - Exchanger head with mirror finishing for Food and Pharmaceutial Industries.
• - Heads gaskets available in EPDM, NBR, SILICON, PTFE.
• - Connections: calmp, flanges, butt welding.
• - Element standart lenght: 1,5 ;  2 ;  3 ;  6 meters.
• - Built-in expansion compansator available for the W (welded heads) versions.
